| Ordering |
|---|
| Country of Origin: |
Finland (FI) |
| Customs Tariff Number: |
85044088 |
| Invoice Description: |
ACS880-07-0635A-5 PN:450kW, IN:635A |
| Made To Order: |
Yes |
| Minimum Order Quantity: |
1 piece |
| Order Multiple: |
1 piece |
| Quote Only: |
No |
| Selling Unit of Measure: |
piece |
| Technical |
|---|
| Number of Phases: |
3 |
| Frequency (f): |
50 / 60 (+/- 5%) Hz |
| Input Voltage (Uin): |
380 ... 500 V |
| Mounting Type: |
Cabinet-built |
| Output Current, Heavy-Duty Use: |
477 A |
| Output Current, Light-Overload Use: |
623 A |
| Output Current, Normal Use: |
635 A |
| Output Power, Heavy-Duty Use: |
315 kW |
| Output Power, Light-Overload Use: |
450 kW |
| Output Power, Normal Use: |
450 kW |
| Ecodesign Exemption: |
Energy efficiency data is not provided for this cabinet-built drive. Cabinet-built drives, with already conform modules, are excluded from the scope of the EU ecodesign requirements (Regulation EU/2019/1781, §2.3.e). |
| Additional Information |
|---|
| Product Main Type: |
ACS880-07-0635A-5 |
| Product Name: |
Frequency Converter |
| Classifications |
|---|
| Product Series: |
ACS880 |
| UNSPSC: |
39122001 |
| Environmental |
|---|
| SCIP: |
e1aec134-b168-4e21-9c40-ee5e90c4bab4 Finland (FI) |
| WEEE Category: |
4. Large Equipment (Any External Dimension More Than 50 cm) |
