ABB CM-CT 200/1 Current transformer 2.5VA, class 1 1SVR450116R1400
ABB CM-CT 200/1 Current transformer 2.5VA, class 1 1SVR450116R1400
Regular price
R 615.18 ZAR
Regular price
R 1,118.50 ZAR
Sale price
R 615.18 ZAR
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
The CM-CT 200/1 is a plug-in current transformer from the CM-CT range. The current transformer has a rated primary current of 200 A and a secondary rated current of 1 A. The burden of the current transformer is 2.5 VA and its precision is according to class 1. The CM-CT 200/1 will be delivered with foot angle, insulating protective cap and bar fastening screws. A snap-on mounting for DIN rail is avaiable as accessory.
Specifications
| Technical | |
|---|---|
| Standards: | IEC/EN 63000IEC/EN 61869-1IEC/EN 61869-2 |
| Function: | Current transformer |
| Suitable For: | CM-SRS.11SCM-SRS.11PCM-SRS.12SCM-SRS.12PCM-SRS.21SCM-SRS.21PCM-SRS.22SCM-SRS.22PCM-SRS.M1SCM-SRS.M1PCM-SRS.M2SCM-SFS.21SCM-SFS.21PCM-SFS.22S |
| Suitable for Product Class: | Single Phase Monitors |
| Rated Primary Current (Ipn): | 200 A |
| Rated Secondary Current (Isn): | 1 A |
| Environmental | |
| RoHS Status: | Following EU Directive 2011/65/EU |
| Dimensions | |
| Product Net Width: | 61 mm |
| Product Net Height: | 78.5 mm |
| Product Net Depth / Length: | 48 mm |
| Product Net Weight: | 0.222 kg |
| Container Information | |
| Package Level 1 Units: | box 1 piece |
| Package Level 1 Width: | 62 mm |
| Package Level 1 Height: | 52 mm |
| Package Level 1 Depth / Length: | 90 mm |
| Package Level 1 Gross Weight: | 0.227 kg |
| Package Level 1 EAN: | 4013614376825 |
| Ordering | |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85043129 |
| Certificates and Declarations (Document Number) | |
| Declaration of Conformity - CE: | 1SVD982015-00 |
| Declaration of Conformity - UKCA: | 1SVD982015-10 |
| Instructions and Manuals: | 1SVC450000M9000 |
| RoHS Information: | 1SVD982015-0001 |
| Regulatory Compliance Mark (RCM): | |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CDC110004C0210_02 |
| Instructions and Manuals: | 1SVC450000M9000 |
| Classifications | |
| ETIM 7: | EC002048 - Current transformer |
| ETIM 8: | EC002048 - Current transformer |
| EPLAN Catalog Tree: | Electrical engineering / General / General |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B: | Business To Business |
| CN8: | 8504 31 29 |
| eClass: | V11.0 : 27210902 |
| Object Classification Code: | T |
