Danfoss Frequency Converter Danfoss FC-302P11KT6P55HXXGXXXXSXXXXAXBXCXXXXD0
Danfoss Frequency Converter Danfoss FC-302P11KT6P55HXXGXXXXSXXXXAXBXCXXXXD0
Regular price
R 44,844.30 ZAR
Regular price
R 64,063.28 ZAR
Sale price
R 44,844.30 ZAR
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Specifications
Gross weight | 22.2 kg |
---|---|
Net weight | 21.9 kg |
Volume | 144.67 l |
EAN | 5702427833258 |
Sales restriction control | |
Matr grp for sales restriction | No grouping |
VLT® AUTOMATIONDRIVE FC 300 SERIES | |
Product View (Switch) | Global (Standard) |
Product Group | VLT® AutomationDrive FC- |
Series | 302 |
Power Rating | (P11K) 11 KW / 15 HP |
Phase | Three phase |
Mains Voltage | 525 - 600 VAC |
Enclosure | IP55 / Type12 Backplate |
RFI Filter | No RFI Filter |
Brake - Safe Stop | No brake chopper |
LCP | Graphical Loc. Cont. Panel |
Coating PCB | Not coated PCB |
Mains Option | No Mains Option |
Adaptation A | Standard Cable Entries |
Adaptation B | No adaptation |
Software Release | Latest release std. SW. |
Software Language Pack | Standard Language Pack |
A Option | No A Option |
B Option | No B Option |
C0 Option MCO | No C0 option |
C1 Option | No C1 option |
C Option Software | No software option |
D Option | MCB-107 24V DC backup |
Frame Size | B1 |
Typecode Part 1 | FC-302P11KT6P55HXXGX |
Typecode Part 2 | XXXSXXXXAXBXCXXXXD0 |
Product Catalog | NO VIEW |
Power 160% (HO) [KW] | 11 |
Power 110% (NO) [KW] | 15 |
Height [mm] | 4800 |
Width w/ no C options [mm] | 2420 |
Depth [mm] | 2600 |
Depth with Option A/B [mm] | 2600 |
kVA | 17.9 |
Power Loss NO [W] | 300 |
Power Loss NO [W] | 300 |
Power Loss HO [W] | 220 |
Power Loss HO [W] | 220 |
Continuous Current (NO) [A] | 23 |
Intermittent Current (NO) [A] | 25.3 |
Continuous Current (NO) [A] | 22 |
Intermittent Current (NO) [A] | 24.2 |
Continuous Current (HO) [A] | 19 |
Intermittent Current (HO) [A] | 30.4 |
Continuous Current (HO) [A] | 18 |
Intermittent Current (HO) [A] | 28.8 |
Calculated Gross Weight [kg] | 22.7 |
Calculated Net Weight [kg] | 22.4 |
Material Gross Weight | 22.2 |
Material Net Weight | 21.9 |
Vendor | Cannot Determine Vendor |
Modelcode01 | FC-302P11KT6P55HXXGX |
Modelcode02 | XXXSXXXXAXBXCXXXXD0 |
