Danfoss
Regular price
R 37,163.41 ZAR
Regular price
R 53,090.59 ZAR
Sale price
R 37,163.41 ZAR
Unit price
/
per
SKU:
Part Number:134G3780
Couldn't load pickup availability
Specifications
|
|---|
| Gross weight |
7.24 kg |
| Net weight |
6.65 kg |
| Volume |
22.04 l |
| EAN |
5710107541010 |
| Sales restriction control |
|---|
| Matr grp for sales restriction |
No grouping |
| VLT® AUTOMATIONDRIVE FC 300 SERIES |
|---|
| Product View (Switch) |
Global (Standard) |
| Product Group |
VLT® AutomationDrive FC- |
| Series |
302 |
| Power Rating |
(P7K5) 7.5 KW / 10 HP |
| Phase |
Three phase |
| Mains Voltage |
525 - 690 VAC * |
| Possible rating issue |
Possible Rating Issue: |
| Enclosure |
(E20) IP20 / Chassis |
| RFI Filter |
RFI class A1 (C2) |
| Brake - Safe Stop |
Brake chopper |
| LCP |
Graphical Loc. Cont. Panel |
| Coating PCB |
Coated PCB |
| Mains Option |
No Mains Option |
| Adaptation A |
Standard Cable Entries |
| Adaptation B |
No adaptation |
| Software Release |
Latest release std. SW. |
| Software Language Pack |
Standard Language Pack |
| A Option |
No A Option |
| B Option |
No B Option |
| C0 Option MCO |
No C0 option |
| C1 Option |
No C1 option |
| C Option Software |
No software option |
| D Option |
No D option |
| Frame Size |
A3 |
| Typecode Part 1 |
FC-302P7K5T7E20H4BGC |
| Typecode Part 2 |
XXXSXXXXAXBXCXXXXDX |
| Product Catalog |
NO VIEW |
| Power 180% (HO) [KW] |
NV |
| Power 160% (HO) [KW] |
7.5 |
| Power 150% (HO) [KW] |
NV |
| Power 110% (NO) [KW] |
NV |
| Height [mm] |
2680 |
| Height w/ Regen/Loadshare [mm] |
NV |
| Width w/ no C options [mm] |
1300 |
| Depth [mm] |
2050 |
| Depth with Option A/B [mm] |
2200 |
| kVA |
12 |
| Power Loss NO [W] |
300 |
| Power Loss NO [W] |
300 |
| Power Loss HO [W] |
300 |
| Power Loss HO [W] |
300 |
| Continuous Current (NO) [A] |
NV |
| Intermittent Current (NO) [A] |
NV |
| Continuous Current (NO) [A] |
NV |
| Intermittent Current (NO) [A] |
NV |
| Continuous Current (HO) [A] |
11 |
| Intermittent Current (HO) [A] |
17.6 |
| Continuous Current (HO) [A] |
10 |
| Intermittent Current (HO) [A] |
16 |
| Calculated Gross Weight [kg] |
7.5 |
| Calculated Net Weight [kg] |
7.2 |
| Material Gross Weight |
7.24 |
| Material Net Weight |
6.65 |
| Vendor |
Cannot Determine Vendor |
| Modelcode01 |
FC-302P7K5T7E20H4BGC |
| Modelcode02 |
XXXSXXXXAXBXCXXXXDX |
