Danfoss
Regular price
R 306,936.91 ZAR
Regular price
R 438,481.30 ZAR
Sale price
R 306,936.91 ZAR
Unit price
/
per
SKU:
Part Number:134H6546
Couldn't load pickup availability
Specifications
|
|---|
| Gross weight |
207 kg |
| Net weight |
157 kg |
| Volume |
0 l |
| EAN |
5710107716739 |
| Sales restriction control |
|---|
| Matr grp for sales restriction |
No grouping |
| VLT® AUTOMATIONDRIVE FC 300 SERIES |
|---|
| Product View (Switch) |
Global (Standard) |
| Product Group |
VLT® AutomationDrive FC- |
| Series |
302 |
| Power Rating |
(N160) 160 KW / 250 HP |
| Phase |
Three phase |
| Mains Voltage |
380 - 500 VAC |
| Enclosure |
(E54) IP54 / Type 12 |
| RFI Filter |
RFI Filter |
| Brake - Safe Stop |
Brake chopper |
| LCP |
Graphical Loc. Cont. Panel |
| Coating PCB |
Coated PCB |
| Mains Option |
Fuse |
| Adaptation A |
Standard Cable Entries |
| Adaptation B |
No adaptation |
| Software Release |
Latest release std. SW. |
| Software Language Pack |
Standard Language Pack |
| A Option |
No A Option |
| B Option |
No B Option |
| C0 Option MCO |
No C0 option |
| C1 Option |
No C1 option |
| C Option Software |
No software option |
| D Option |
No D option |
| Frame Size |
D7H |
| Typecode Part 1 |
FC-302N160T5E54H2BGC |
| Typecode Part 2 |
7XXSXXXXAXBXCXXXXDX |
| Product Catalog |
Global (Standard) |
| Power 180% (HO) [KW] |
NV |
| Power 160% (HO) [KW] |
NV |
| Power 150% (HO) [KW] |
160 |
| Power 110% (NO) [KW] |
200 |
| Height [mm] |
19780 |
| Height w/ Regen/Loadshare [mm] |
NV |
| Width w/ no C options [mm] |
4200 |
| Depth [mm] |
3860 |
| Depth with Option A/B [mm] |
3860 |
| kVA |
218 |
| Continuous Current (NO) [A] |
395 |
| Intermittent Current (NO) [A] |
435 |
| Continuous Current (NO) [A] |
361 |
| Intermittent Current (NO) [A] |
397 |
| Continuous Current (HO) [A] |
315 |
| Intermittent Current (HO) [A] |
472 |
| Continuous Current (HO) [A] |
302 |
| Intermittent Current (HO) [A] |
453 |
| Calculated Gross Weight [kg] |
200.3 |
| Calculated Net Weight [kg] |
200 |
| Material Gross Weight |
207 |
| Material Net Weight |
157 |
| Plant from Orderline |
B601 |
| Vendor |
Cannot Determine Vendor |
| Modelcode01 |
FC-302N160T5E54H2BGC |
| Modelcode02 |
7XXSXXXXAXBXCXXXXDX |
