ABB
ABB DB45EF Single Mounting Kit 1SAX201910R0001
ABB DB45EF Single Mounting Kit 1SAX201910R0001
Regular price
R 319.17 ZAR
Regular price
R 597.72 ZAR
Sale price
R 319.17 ZAR
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
DB45EF Single Mounting Kit for EF45
Specifications
| Ordering | |
|---|---|
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85389099 |
| Popular Downloads | |
| Data Sheet, Technical Information: | 2CDC107025D0201 |
| Instructions and Manuals: | 2CDC107046M6802 |
| Dimension Diagram: | 1SAX200404F0001 |
| Dimensions | |
| Product Net Width: | 45 mm |
| Product Net Height: | 130 mm |
| Product Net Depth / Length: | 98 mm |
| Product Net Weight: | 0.1 kg |
| Technical | |
| Number of Poles: | 3 |
| Connecting Capacity Main Circuit: | Flexible with Ferrule 1x 2.5 ... 10 mm²Flexible with Insulated Ferrule 1x 2.5 ... 10 mm²Flexible 1x 2.5 ... 10 mm²Rigid 1x 2.5 ... 16 mm² |
| Tightening Torque: | Main Circuit 0.8 ... 1.5 N·m |
| Wire Stripping Length: | Main Circuit 15 mm |
| Recommended Screw Driver: | Pozidriv 2 |
| Suitable For: | EF45 |
| Standards: | IEC/EN 60947-1IEC/EN 60947-4-1UL 60947-1UL 60947-4-1 |
| Technical UL/CSA | |
| Connecting Capacity Main Circuit UL/CSA: | Flexible 1x 14-6 AWGStranded 1x 14-6 AWG |
| Tightening Torque UL/CSA: | Main Circuit 7 ... 13 in·lb |
| Environmental | |
| RoHS Status: | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Certificates and Declarations (Document Number) | |
| Declaration of Conformity - CE: | 1SAD938519-0180 |
| Declaration of Conformity - UKCA: | 1SAD938502-1180 |
| Instructions and Manuals: | 2CDC107046M6802 |
| RoHS Information: | 1SAD938519-0180 |
| UL Certificate: | E48139-19990512 |
| Container Information | |
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 135 mm |
| Package Level 1 Height: | 104 mm |
| Package Level 1 Depth / Length: | 48 mm |
| Package Level 1 Gross Weight: | 0.124 kg |
| Package Level 1 EAN: | 4013614493393 |
| Classifications | |
| ETIM 4: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 5: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 6: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 7: | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8: | EC002498 - Accessories/spare parts for low-voltage switch technology |
| eClass: | V11.0 : 27371392 |
| UNSPSC: | 39122221 |
| IDEA Granular Category Code (IGCC): | 5219 >> Switch part or accessory |
| E-Number (Finland): | 3709422 |
