Danfoss
Danfoss Frequency converter 135N5634
Danfoss Frequency converter 135N5634
Regular price
R 9,772.77 ZAR
Regular price
R 13,961.10 ZAR
Sale price
R 9,772.77 ZAR
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Gross weight | 6.3 kg | ||
| Net weight | 6 kg | ||
| Volume | 0 l | ||
| EAN | 5710108218324 |
VACON 0100
| Product View (Switch) | GLBL | Global (Standard) | |
| Segment | -FLOW | VACON 100 FLOW | |
| Region Code | -R00 | R00 International | |
| Mains voltage | -2 | 208–240 Vac | |
| Current rating | -0011 | 11 Amp | |
| Installation options | -DM | DM Drive Module | |
| Enclosure | +IP21 | IP21/NEMA1 | |
| Control panel | +HMGR | Graphical Keypad MK01 | |
| EMC emission limit category | +EMC2 | C2 Commercial&Industry Environ | |
| Common mode filter (for DM) | +P000 | No Option | |
| DUT filter (for DM) | +P000 | No Option | |
| Brake chopper | +DBNO | No dynamic braking device | |
| Real time clock option | +SRNO | No Battery for real time clock | |
| Configurable power range | NONE | None | |
| Power connections | +P000 | No Power options (+P000) | |
| Cable entry | +QGLM | Metric conduit plate | |
| Additional Equipment B | +Q000 | No option for Qxxx_B (+Q000) | |
| Additonal Equipment C | +Q000 | No additonal option for Qxxx_C | |
| Shipping package | +GSCB | Cardboard Box as Shipping pack | |
| Marine construction | +E000 | no option | |
| B-Slot Option Board | +SBF3 | F3,3 Relay board | |
| C- Slot Option Board | +SC00 | No board | |
| D-Slot Option Board | +SD00 | No board | |
| E-Slot Option Board | +SE00 | No board | |
| Internal FB selection | +FBM1 | Std protocol,Modbus,N2,BacNet | |
| Documentation level | +DQCK | Quick Guide | |
| Document language preference | +DLUK | English | |
| Firmware Language Pack | +FL01 | UK, DE, FI, SE, IT, FR lang | |
| Application | +A0000 | No Application | |
| Parameter Set | +L0000 | No application parameter set | |
| Motor parameter default freq | +LS50 | 50 Hz def motor freq settings | |
| Unit for measure for display | +LSSI | Metric Units of Measure | |
| Labeling options | +LPC1 | no additional labels | |
| UL approval | +GAUL | UL Approval (+GAUL) | |
| Marine approval | NONE | None | |
| RCM Approval | +GACT | RCM Approval N16307 | |
| KC approval | +GAKC | KC Approval | |
| Ukrainian approval | +GAUA | Ukrainian Approval | |
| EAC Approval | +GAEA | EAC Approval | |
| Auxilary power supply | +C000 | no option | |
| DC power supply for aux device | +C000 | no option | |
| AC socket for aux devices | +C000 | no option | |
| Input Devices | NONE | none_ | |
| Common mode filter (for ED) | +P000 | no option | |
| DU/DT, Sine filter (for ED) | +P000 | no option | |
| Terminal Options | NONE | none_ | |
| Door Equipments | +C000 | no option | |
| Cabinet heater | +C000 | no option | |
| Cabinet light | +C000 | no option | |
| Motor heater control | +C000 | no option | |
| Emergency stop options | +C000 | no option | |
| Insulation fault sensor | +C000 | no option | |
| Cabling from top | +C000 | no option | |
| Back channel cooling | +C000 | no option | |
| Cabinet Plinth | +C000 | no option | |
| Empty extension segment | NONE | None | |
| Standardized cabinet solution | NONE | None | |
| Engineered cabinet solution | NONE | None | |
| Product Group | VACON | VACON | |
| Product Series | 0100 | Vacon 100 series | |
| Phase | -3L | 3 Phase AC Input | |
| Customized | +BM2H | Vacon 100-FLOW | |
| Main Circuit | +M000 | NONE | |
| Firmware | +F0159 | Vacon0100-Flow Software pack | |
| Max output frequency | NONE | None | |
| Terminal Box | +T000 | NONE | |
| Bypass Control Operation Mode | NONE | none_ | |
| Bypass Input Type | NONE | none_ | |
| Bypass power connection type | NONE | none_ | |
| CE approval | +GACE | CE Approval (+GACE) | |
| ATEX Approval | NONE | None | |
| County Specific Approval | NONE | None | |
| Warrenty time | +WT01 | Warranty 12/18 months (+WT01) | |
| Frame Size | MR04 | Frame 04 | |
| Product Catalog | NO_VIEW | NO VIEW | |
| Modelcode01 | VACON0100-3L-0011-2 | ||
| Modelcode02 | -FLOW | ||
| Calculated Net Weight [kg] | 6 | ||
| Calculated Gross Weight [kg] | 7 | ||
| Motor Power Low Overload [kW] | 2,2 | ||
| Dimensions WxHxD [mm] net | 128 X 328 X 190 | ||
| Dimensions WxHxD [mm] Gross | 175 X 384 X 232 | ||
| Dimensions WxHxD [mm] | 128X328X190 | ||
| Continuous Current (NO) [A] | 11 | ||
| Motor Power HP Low Overload | 3 | ||
| Typecode Part 1 | 70-AB3L00112W04B220BM2H | ||
| Typecode Part 2 | -00050393 | ||
| Stockcode part 1 | 70-AB3L00112W04B220BM2H | ||
| Stockcode part 2 | -00050393 | ||
| check if complete | OK | ||
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Help Counter | 5 | ||
| Help Counter | 2 | ||
| Calculated Net Weight | 6 | ||
| Salestext | MR04-0011-2+IP21+EMC2 | ||
| Sub family identification | NONE | Normal customer ordered | |
| Recommended Plant | ERR01 | ||
| ECCN US | 3A999.a | ||
| ECCN EU | X.A.I.003 |
